Description

Specifications ∶
　 ·Parameters: WBC, LYM#, MID#, GRAN#, LYM%, MID%, GRAN%, RBC, HGB, HCT, MCV, MCH, MCHC,RDW-CV, RDW-SD, PLT, MPV, PDW, PCT,P-LCR,P-LCC
　 3-part differentiation of WBC, 21 parameters and 3 histograms
　 ·Principles of operation:WBC/RBC/PLT: Electrical Impedance
　　　　　　　　 HGB: Photoelectric colorimetry
　 ·Aspiration Volume:Whole blood 10uL,Pre-diluted 20uL
　 ·Aperture Diameter:WBC 100um,RBC/PLT 68um
　 ·Throughput:60 samples per hour
　 ·Data storage:More than 100,000 sample results with histograms
　 ·Alarms: Error messages
　 ·Dilution Ration: 　　　　　　　 Whole blood 　　　 Capillary blood
　　　　　　　　 WBC/HGB 　　　　1:232 　　　　　　1:400
　　　　　　　　RBC/PLT 　　　　1:40000 　　　　　 1:45000
　 ·Display: 10.4 inches color LCD
　 ·Control and calibration: L-J,X,X-R,X-B four control modes,manual and auto-Calibration System check
　 ·Dimension: 330mm x 440mm x 500mm
　 ·Power requirement: AC 100V — 240V, 50/60Hz, 180W
　 ·Input/Output: Support RS232, standard network port and USB
　　　　　 Shortcut keys with standard mouse and keyboard
　　　　　 Internal 57mm thermal printer,
　　　　　 Parallel Port and USB for external printer

Characteristics :
　 ·Large color LCD display & Linux operation system
　 ·Support USB data backup & system upgrade
　 ·Excellent data management with mouse and keyboard
　 ·High efficient self checking system, low maintenance
　 ·Support LIS and HIS with HL7 protocol
　 ·Collaborator of BIO-RADcontrol,target value available

counting results

Counting-results
System Maintenance

system maintenance
